Intricate Wings Design
in3D Modeling Designheld byKiroLast seen:
Contest Ended, Winner(s) have been selected.
-
Open
-
Choosing Finalist
-
Ended
Description:
- Small wings design based on a 2D picture provided- Each wing to be separate with a little loop at the top so as to have a necklace looped through the top
- Must be able to be 3D printed
- Jewellery will be made from a white metal which will be 3D printed (by Shapeways.com)
- Design end product must have the layers so as to depict the image as set out by the 2D file provided
Wants:
- Minimum thickness of width of the jewellery is 1mm (to be able to be printed properly)- Dimensions of the wings themselves should be: Width - 25mm at it's widest part (the top of the wing). Height - 30mm. Thickness - Between 1mm and whatever thickness you deem fit to portray the depths of the picture properly
- Must have added loop at the top of each separate wing to have a necklace (thickness 2mm) looped through, so that the wings hang from it without part of the design being taken
- End product will be tested on Shapeways upload section of their website
Don't Wants:
- Unmanufacturable designs (from Shapeways.com)- Bulky looking
Software:
- AutoCAD (2010)
Prepaid PrizeEntries
Discussion
Showing last 20 comments -View All
Could you please make the minimum thickness 1.6mm please. Thank you.
Morgan: That would be acceptable.
为了保持相同的长宽比,dimensions would become approximately 25mm wide by 60 mm long, would this be acceptable?
Albertus Putra: If you made the wings bigger, would the drawing and the crossing of the frame be avoided?
Zyrone Levanthino: I will need almost all of the details to be visible.
Zyrone Levanthino: I will need almost all of the details to be visible.
hi sir, because there is too much detail within the design. Like the human figure and other things. If its of without it it will be fine.
There is a problem if you want to make a separate parts (wings and drawings), the drawing sometimes cross the wing frame (cross in & out). So, the drawings are not really inside the wing frame.
What is your advice for this problem?
What is your advice for this problem?
This is the first time commissioning a project. Plus, I still need to pay for the actual production of the jewellery which will cost more money.
Creating what you want seem really exciting but the price seems to low for the projects.
Thank you for the info. I know now how it works.
The drawings should be a part of the 3D representation, so either have the drawings a different thickness. Or have the background of the drawings one piece of the wing, and the then the drawings can be overlaid ontop of the background as another separate piece. I would prefer it the second way, that way, the back piece (the not drawings) can be made of silver, and the front piece (the drawings) can be made of gold.
That is (all in all) 4 pieces, 2 pieces form one wing and another 2 pieces form the other wing.
I am also not sure what Zyrone Levantino is talking about, I am unfamiliar with that terminology, but I hope this link from Shapeways can be of help:
https://www.shapeways.com/tutorials/supported-applications?li=nav
That is (all in all) 4 pieces, 2 pieces form one wing and another 2 pieces form the other wing.
I am also not sure what Zyrone Levantino is talking about, I am unfamiliar with that terminology, but I hope this link from Shapeways can be of help:
https://www.shapeways.com/tutorials/supported-applications?li=nav
the drawings are to be included to the 3d?drawings within the wings
Hi sir, Can a 3d model in 3ds max properly model be printed in shapeway?
Thanks
Thanks
But I'm not sure about the gaps, but we'll see where it goes when i can view the 3D model
Ok, look forward to seeing it in 3D
It is still in 2D, once i have generate in 3D i'll upload it again.
I just wanted to make sure my direction is correct... :)
I just wanted to make sure my direction is correct... :)
Yes, just like that loop, but I can't see it on the design you submitted. Plus the picture that you submitted, it doesn't have a loop.
Hi,
I think the loop is like this:
http://www.shapeways.com/model/325478/ravenclaw-crest-necklace.html?materialId=23
Is it correct?
Regards
Zulfadzryl
I think the loop is like this:
http://www.shapeways.com/model/325478/ravenclaw-crest-necklace.html?materialId=23
Is it correct?
Regards
Zulfadzryl
The loop is so that a necklace can go through it. Her neck doesn't go through the loop.
can you measure the diameter of her neck? so we can know the dimension for the loop
Yea, the missus loves Coldplay and I can't find wings like it as jewellery. A one of a kind would make her so happy. Yes, as detailed as possible to create, so as when it becomes 3D printed, you can see the details. It's up to you if you want to make it one piece for each wing, or make it as two pieces (where one would be the wing around the specific details, and the other piece would fit into the grooves of the first piece showing the details, and have both pieces made of different metals)
