The gentlemans shaver
in3D Modeling Designheld bycmglobalLast seen:
Contest Closed
-
Open
-
Choosing Finalist
-
Ended
Description:
We need a design for a shaver handle. The design should have an exclusive look to it, not "spacey" as many established brands are. Keywords for the design could be "gentleman, scandinavian, hipster, modern man, elegant, James Bond, simple" and such.What we need is a design made in CAD, and ultimately files ready for production, our current setup requires .dwg or .dwt files. But we would like to see an realistic 3d render of the handle.
There are though some specifications for the connection between the handle and the razor blades that should be met. Since the connection is an standard set of from our razor-blade production partner. In the attached files there are an example of an handle and the lock mechanism, so the way the blades are connected and the sliding lock works should be thought into the design.
It's for the scandinavian market, so the design should fit in there, and should ofcourse have a good grib, size and weight to it. We have a target weight of minimum 50-60gr to the handle.
Wants:
The design is the single most important thing. But also things as color, ergonomy, overall look and feel plays a part.
Don't Wants:
We dont want an design that looks like the large established brands, the design should have either incorporated the lock and connection mechanism, or at least it should be possible to make or incorporate in the design
Software:
- AutoCAD
Payment PendingEntries
Discussion
Still looking for more designs? I'm working on some right now but i'm not sure if this project is even still active.
A suggested link for an established brand with a similar concept; http://www.theartofshaving.com/razors/razors,default,sc.html Just needs more 90 degree angles and it's contemporary.
Hi Eduardo, Im not that familiar with all the different software, but as I see it on google etc. yes you can. It should be able to export/save it as a .dwg format
Hi can I use CATIA or Unigraphics NX software to design the handle?
