Telescoping Pet RampBlind
inIndustrial Design Servicesheld bytoddcoziwowLast seen:
Contest Ended, Winner(s) have been selected.
-
Open
-
Choosing Finalist
-
Ended
Description:
We are an e-commerce company doing business on Amazon, eBay, Walmart and our e-commerce website.We want to design a pet ramp like this urlwww.amazon.com/dp/B000RUJEUU/ref=sspa_dk_detail_1
It is made of aluminium alloy material.
It is a telescopic structure.
It's used for pets such as dogs, cats, pigs, rabbits and so on.
In fact, we have a pet ramp sold very well. However, we need more excellent products.
Wants:
-Made of Aluminium alloy material.-Telescopic structure (Adjustable Sizing).
-Lightweight.
-Must be different from the sample.
-Must be different from the designs of the other products in Amazon.
-Nice.
-Distinctive.
-With one creative feature at least.
-The file type must be step.
-Must help us modify it until 3D printing ended.
The critical point is whether customers like it. Give full play to your imagination and professional ability. Please give us an excellent design.
We like Cadcrowd, and we will observe the rules of Cadcrowd. If excellent design, we must select. We have finished one smooth contest on Cadcrowd. And we will issue another project soon. Welcome to take part in it.
Don't Wants:
Copy it from Amazon or eBay or other e-commerce websites without any creativity.Bad experience when customers use.
Slipping when a pet walks on it.
Ask for Sample:
https://www.amazon.com/dp/B000RUJEUU/ref=sspa_dk_detail_1?th=1
Software:
- PTC Creo Parametric / Pro-E (UG NX)
Additional Information
It's my second time to use Cadcrowd. It was a good experience last time.We just set 1 prize last time cause it was our first time to use that we did not know the rule.
This time we will set 2 or 3 prizes for the Telescoping Pet Ramp. Of course, if we get more excellent designs, we will set 5 prizes. We will add it when we find there are many good designs. We want to get more great designs. It's easy to manufacture Pet Ramps.
PS: You can use ProE\UG\SOLIDWORKS， we need step type file.
Prepaid Prize
Entries
Discussion
Hello,
is the design limited to a telescope mechanism or is it possible to come up with any adjustable concept?
I am with Albertus. A telescope isnt the best solution here.
is the design limited to a telescope mechanism or is it possible to come up with any adjustable concept?
I am with Albertus. A telescope isnt the best solution here.
@Albertus Putra Welcome to join it. Come on, Albertus.
谢谢你the invitation;
I saw some ramps are using different mechanism, like scissor mechanism;
DO you think we can develop other mechanism too?
I think the best feature is if we can fold the ramp with minimum space required
I saw some ramps are using different mechanism, like scissor mechanism;
DO you think we can develop other mechanism too?
I think the best feature is if we can fold the ramp with minimum space required
@Prabhakarmetri I'm not a designer and I don't know how to use CATIA. In one word, we need step file that ProE can open. Because our manufacturing department can just use ProE and UG.
I have CATIA V5 software,but i can send you a step file, can i proceed???
Dear every designer, I have confirmed that you can use solidwork. But we need step type file. Thank you.
@Taguida Med pls check the sample url, there are specifc dimentions. I don't like write specifc dimentions here. Because I don't like to limit the designer's imagination. Customers' experience is most important. We need amazing designs. Come on, designers, let me see cadcrowd power!
@Filippo Ranieri @Elise King We need step file. Because our mould department is good at step file for Proe & UG. Can solid works file converted to step file? I don't know. If you have the solution, you can try but tell me the converting idea.
specifc dimentions ?
I have the same question as Filippo, I can certainly create a Solid works file and sent you a step file so that it can be viewed in NX.
You got a problem if i design with solidworks?
hi,
i want to know what file type you need
i want to know what file type you need
