Description:
Hi,I need a technical drawing of a product idea that I would like to send to manufacture's so they can create a prototype.
The idea is an in-car vending machine/box that can fit snacks and other small items. It needs to fit on the middle/center console of the car (example picture attached). I would want a box that is modern/techie.
The box needs to be unique but similar to the example pictures I'm going to attach.
Three main components:
小镇的盒子
清晰的盖子
-Dividers
Dimensions:
-Length: 13 - 13.5 inches
-Width: 8 inches
-Height: 4 - 4.5 inches
Wants:
I am looking for unique esthetics and design. Modern and tech focused.
Don't Wants:
Do not copy the example photos, please. It has to be different and unique.Entries
Discussion
Please can the submission date be extended?
Tue, 11 Feb 2020 04:53:32 +0000
My team will crush this design, help you prototype it, create pre-production units and select a manufacturer - mass production or small volume. We are new to Cad Crowd, but have a Product Development firm with a wealth of experience. This is a great idea, and posting it like this puts you in a race to get to market. We can help.
坐,08年2月2020 08:35:04 +0000
I can think of three to five different ways of doing it.. and I could produce a prototype. Not really going to hand over at design for a chance to win two hundred bucks? Kind of an interesting little product though.
Fri, 07 Feb 2020 17:57:33 +0000
I would request you to prepay.
