Donkey Calf Raise attachment Quick ConnectBlind
inMechanical Engineeringheld byAchillesLast seen:
Contest Ended, Winner(s) have been selected.
-
Open
-
Choosing Finalist
-
Ended
Description:
This contest is to design a fast way to connect and disconnect the Donkey Calf Raise attachment to various size smith machine barbell shafts. The Donkey Calf Raise attachment is a patented apparatus that can be attached to the smith machine barbell to perform the donkey calf raise exercise. The current design will not attach to all smith machine barbell shafts. I need a new quick way for the apparatus to attach to a 25mm to 35mm diameter smith machine barbell shaft.Please see attached 3D STEP file, Inventor assembly & part files and AutoCAD 3D file. Attached also are images on how to perform the donkey calf raise exercise.
Wants:
•快速连接和断开连接to a smith machine barbell shaft• Commercial grade construction
• Must be very durable to withstand constant use
• Modern looking design
• It should be able to fit 25mm to 35mm diameter smith machine barbell shafts.
• Material: Aluminum
• All Designs will be 3D Solid Models
Don't Wants:
• Do not change the overall design; just change the way it connects to the smith machine barbell• We do not want overly complex designs that are difficult to manufacture. Keep it simple
Software:
- Software that can be used: • Autodesk Inventor, Pro Engineer, SolidWorks, Solid Edge, Catia, Unigraphics
Entries
#72Donkey calf raise - adaptive designbyAleandro Saez
Download Files
- Autodesk Inventor 2019 — 1 - 25mm attached upper view
- Autodesk Inventor 2019 — 2 - DONKEY attachment 25mm
- Autodesk Inventor 2019 — 3 - DONKEY attachment 35mm
- Autodesk Inventor 2019 — 4 - Adaptive attachment
- Autodesk Inventor 2019 — 5 - Spring - Adaptive attachment
- Autodesk Inventor 2019 — 6 - Random view
May 28, 2019 10:22
#11Donkey Calf Raise attachment Quick Connect-submissionbyjithesh
Declined
Download Files
- 3ds Max (3D Studio Max) 2019 — view1
- 3ds Max (3D Studio Max) 2019 — view2
- 3ds Max (3D Studio Max) 2019 — view3
- 3ds Max (3D Studio Max) 2019 — view4
- 3ds Max (3D Studio Max) 2019 — with mechine 1
- 3ds Max (3D Studio Max) 2019 — with mechine2
- 3ds Max (3D Studio Max) 2019 — with mechine3
- 3ds Max (3D Studio Max) 2019 — with mechine4
May 4, 2019 13:40
#71Donkey Calf Raise attachment Quick ConnectbyKristian
Download Files
- Autodesk Inventor 2018 — Assembley
- Autodesk Inventor 2018 — DCRA Base Plate V01 v2
- Autodesk Inventor 2018 — DIN 912 M8 X 35 v1
- Autodesk Inventor 2018 — Hook.V01 v3
- Autodesk Inventor 2018 — Pin D 8 x 56
- Autodesk Inventor 2018 — Piston.V01 v12
- Autodesk Inventor 2018 — Spring v7
- Autodesk Inventor 2018 — UpperCase.V01 v12
- STEP/STP 3D Modeling — Assembley v2
May 28, 2019 6:32
Discussion
Hey CH,
Regarding the interface between the shaft and the DCRA connection, does the DCRA rotate around the shaft or will it be fixed i.e not rotate at all? Thanks.
Regarding the interface between the shaft and the DCRA connection, does the DCRA rotate around the shaft or will it be fixed i.e not rotate at all? Thanks.
Buyer
Designer, I have received some good designs but nothing that I would call a winner yet. Let’s keep in mind what this device will be used for. It will be used in a commercial gym. This means that the device will be used quite often and it must be very durable. Also, the attachment clamp must be easy to take off and on the barbell. It must be able to clamp around a 25, 26, 27, 28, 29, 30, 31, 32, 33, 34, and 35mm barbell shaft.
You must also think about how this device will be manufactured.
You must also think about how this device will be manufactured.
Buyer
There is also A 3D STEP file attached.
Designer
can you please upload the files with an extension other than .ipt, solidworks is having trouble identifying the files.
Buyer
Designers, the new design must be able to attach to 25mm, 26mm, 27mm, 28mm, 29mm, 30mm, 31mm, 32mm, 33mm, 34mm and 35mm barbell shafts.
Buyer
Designers,
I want the new connection design to be quick. No threads. Threads take too long to take off and on.
I want the new connection design to be quick. No threads. Threads take too long to take off and on.
Designer
could you upload all fill that you attachment than I can open them on SOLIDWORKS. some files need inventor software to open
Buyer
rhınoceros can work
Tue, 30 Apr 2019 13:15:04 +0000
ıs rhınoceros work ?
Tue, 30 Apr 2019 04:13:27 +0000
The specification 25mm to 35mm barbell... am I to understand that there are only 2 sizes, 25 and 35? or are there sizes in between?
Tue, 30 Apr 2019 03:18:41 +0000
Hi, must the clamp tightly grip the barbell shaft? I measure the current design diameter is 28mm.
Buyer
Designers please make sure that your design quick connect will accommodate a 25mm to 35mm diameter smith machine barbell shaft.
Thanks,
Fabian
Thanks,
Fabian
Buyer
Designers, when submitting ideas; please submit JPG images.
Thanks,
Fabian
Thanks,
Fabian
