Mechanical Engineer to develop light guides or light pipes used with LEDs

in3D Modeling Designheld byjflagle
Contest Ended, Winner(s) have been selected.
  • Open
  • Choosing Finalist
  • Ended
Description:
Looking for an engineer that has experience with light guides or light pipes used with LEDs, and that can design a few simple light guides for an electronic device. 3 LEDs - red, green, blue will feed the light pipe. the other end of the light pipe will be visible to the user thorugh a cutout in the enclosure. the user will see this end of the light pipe, which is 2 strips each at .2 wide x 2" long. there may be some curvature to these 2" long strips (maybe a radius of 2.5"). when the red LED is on the strips will light up red. same for green, etc. need to make sure the lighting is continuous (not brighter at one end than the other). Proven experience with LIght pipes is required. $100 for initial sketch and background proving that this design will work. Further work would then be given to winner to develop the concept into a injection molded part. Good Luck and I look forward to working with you.
Wants:
light pipe design must be able to be converted into an injection molded light guide with a cost of less than 1.00 per part at 1000pc lot size. needs to be assembly sketch with lightpipes and LEDs, and part sketches for each light pipe. see attached pg2. sketch with dimensions, material, and engineering proof (design guides, other similar products, prior experiences, etc) that the concept will work. Bonus points will be given to designs turned in by 9/21/2016
Software:
  1. SolidWorks
Additional Information
Any design must inlcude the following for consideration: 1) the concept must include sketch/model of the actual light guides with dimensions, and any surface treatments etc. and sketch/model of the assembly showing how they are held to circuit board and housing.
