Description:
A De Laval nozzle for supersonic kinetic spraying.
Wants:
Nozzle dimensions (mm):- Inner diameter: 10
- Throat diameter: 6
- Exit diameter: 8.8
- Length of the converging section: 40
- Length of the diverging section: 100
The above dimensions must be exact. However the size and shape of the nozzle externally is left up to you, considering the following:
350°C air enters the nozzle at 6 bar. It is connected to the air compressors 1/2" male adapter. Therefore a 1/2" female thread will be needed to connect the parts together.
Suspension liquid enters the gas flow in the supersonic part of the nozzle and is atomized by the gas cross-flow. The tube connected to nozzle which supplies the suspension has a 1/4" male adapter, so a 1/4" female thread will be needed.
The design does not need to include the female threads as they will be added after the CNC process (another version of the design showing these [threads] would be favorable). Just know that the space and position of these threads will need to be factored into your design.
Thank you very much.
P.S. The software used for the CNC process is unknown at the moment, so if at all possible, please include a few of the most popular file types.
